btsr MATRIX CUBE Operating Manual page 112

Management of "Tension Error" Alarm
UNICO
P4.8
This function allows you to set up the automatic detection feature of a possible
intelligent accessory connected to the DIAPER FEEDER device.
The detection condition is indicated by the lighting of label P4.
for 3 seconds to toggle between
to confirm and return to P4 menu.
to return to
CONTROL
EXAMPLE
The DIAPER FEEDER generates the "Error Tension" Alarm when the tension
goes out of the programmed tolerance band and automatically resets the alarm
as soon as the tension returns within the programmed tolerance band.
"Error Tension" Alarm active only when the DIAPER FEEDER device operates
with P1 tension (
MAIN TENSION
Main Tension: 2.0 g.
± 0.5 g.
Error Tension:
Time Alarm: 2.0 sec.
MATRIX CUBE
and
AUTO OFF
status.
)
DIAPER FEEDER Device
.
