5.1.3 Coil separator adjustment

− For yarn coil separator adjustment operate on the screws indicated below
Even if the torque of motor driving the roller rotation is very low and does not involve hazards for
the operator safety, it's always advisable to lock the motor prior to operate on the devices (yarn
threading, tilt adjustment of coil separation element, etc.) in order to avoid unexpected motor
startup events.
To lock the motor, just press the
of buttons' red LEDs and of TS44 sensor. At the end of the operation, press again the
and make sure that all the red LEDs turn off.
Yarn coil separator
adjustment screws
button on the DIAPER FEEDER device and check the lighting
MATRIX CUBE
Preventive Ordinary Maintenance
button
