Single Device Numbering (DIAPER FEEDER)
To number a single DIAPER FEEDER device (for instance in case of replacement) operate as follows:
EXIT to return to configuration menu.
•
Carry out all the operations described on Device
Configuration and Numbering paragraph, until the
screen showing the Current TS55 and total device
numbers appears on the terminal display.
•
To move immediately to the DIAPER FEEDER
numbering procedure.
•
Select the DF IDENTIFY
FEEDER identification screen.
•
Select on the CURRENT
be re-numbered (e.g. 002).
•
Press Enter on DIAPER FEEDER device number 002
and check that:
a) The red LED of TS44 tension sensor turns off and
the LEDs of Control, Enter and Reset buttons
remain steady green.
b) The display of numbered device shows the
assigned number (e.g. 002).
To leave the identification procedure once you have re-
numbered the desired device.
EXIT to return to configuration menu.
MATRIX CUBE
WEB UP function
option to open the DIAPER
field, the number of device to
