Offset on TS55 and/or
DIAPER FEEDER Devices
This function allows you to carry out the Offset operation on all the connected devices (TS55 sensors and
DIAPER FEEDER devices) or on a specific device range.
Offset on TS55 Sensors
We remind you that, prior to confirm the offset execution, it is necessary to remove the yarn from the
loading cell.

Offset on TS55 and/or DIAPER FEEDER Devices

SETUP →
Enter the SETUP menu.
Select SERVICE.
Select TS55 OFFSET
Select the device range on which you want to carry out the
offset operation (in this example: TS55 sensors on 002,
003 and 004 positions).
Confirm the selection.
OFFSET to carry out the operation on selected device
range,
BACK to return to previous screen without performing the
offset operation,
EXIT to return to setup menu.
A temporary OFFSET EXECUTE
the SERVICE menu will be resumed.
MATRIX CUBE
SERVICE → TS55 OFFSET
DF OFFSET
window will appear, then
