Keypad Operation Procedure - INVT Goodrive100 Series Instruction Manual

Goodrive100 inverters

4 Keypad Operation Procedure

The keypad is used to control Goodrive100 series inverters, read the state data and adjust parameters.
Serial
Name
No.
State
1
LED
Fig 4-1 Keypad
RUN/TUNE
FWD/REV
LOCAL/REMOT
TRIP
IKR Aandrijven en Besturen
www.ikr-industries.nl
Keypad operation procedure
Description
LED off means that the inverter is in the stopping
state; LED blinking means the inverter is in the
parameter autotune state; LED on means the
inverter is in the running state.
FED/REV LED
LED off means the inverter is in the forward rotation
state; LED on means the inverter is in the reverse
rotation state
LED for keypad operation, terminals operation and
remote communication control
LED off means that the inverter is in the keypad
operation state; LED blinking means the inverter is
in the terminals operation state; LED on means the
inverter is in the remote communication control
state.
LED for faults
LED on when the inverter is in the fault state; LED
off in normal state; LED blinking means the inverter
