INVT Goodrive100 Series Instruction Manual page 187

Goodrive100 inverters
The power of the inverter
Note:
1. The rated derate voltage of the input reactor is 2%±15%.
2. The power factor of the input side is above 90% after adding DC reactor.
3. The rated derate voltage of the output reactor is 1%±15%.
4. Above options are external, the customer should indicate when purchasing.
C.6 Filter
Goodrive100 series inverters have embedded C3 filters which can be connected by J10.
The input interference filter can decrease the interference of the inverter to the surrounding equipments.
Output interference filter can decrease the radio noise cause by the cables between the inverter and the
motor and the leakage current of the conducting wires.
Our company configured some filters for the convenient of the users.
The inverter
GD100-5R5G-4
GD100-7R5G-4
GD100-011G-4
GD100-015G/-4
IKR Aandrijven en Besturen
www.ikr-industries.nl
Appendix C
Input reactor
ACL2-5R5-4
ACL2-7R5-4
ACL2-011-4
ACL2-015-4
Input filter
Output reactor
OCL2-5R5-4
OCL2-7R5-4
OCL2-011-4
OCL2-015-4
Output filter
