INVT Goodrive100 Series Instruction Manual page 115

Goodrive100 inverters
Function
Name
code
Simple PLC
P10.00
means
Simple PLC
P10.01 memory
selection
Multi-stage
P10.02
speed 0
The running
P10.03
time of stage 0
Multi-stage
P10.04
speed 1
Detailed instruction of parameters
1:Opposite to the setting direction
P10 Group Simple PLC and multi-stage speed control
0: Stop after running once. The inverter has to be
commanded again after finishing a cycle.
1: Run at the final value after running once. After finish a
signal, the inverter will keep the running frequency and
direction of the last run.
2: Cycle running. The inverter will keep on running until
receiving a stop command and then, the system will stop.
0: Power loss without memory
1:Power loss memory；PLC record the running stage and
frequency when power loss.
100.0% of the frequency setting corresponds to the Max.
Frequency P00.03.
When selecting simple PLC running, set P10.02~P10.33 to
define the running frequency and direction of all stages.
Note: The symbol of multi-stage determines the running
direction of simple PLC. The negative value means reverse
rotation.
Multi-stage speeds are in the range of --f
be
Goodrive100 series inverters can set 16 stages speed,
selected by the combination of multi-stage terminals 1~4,
IKR Aandrijven en Besturen
www.ikr-industries.nl
Keypad operation procedure
~f
max max
Default
value
0
0
0.0%
0.0s
and it can
0.0%
Modify
○
○
○
○
○
