INVT Goodrive100 Series Instruction Manual page 70

Goodrive100 inverters
Function
Name
code
Keypad setting
P04.28
voltage
Voltage
P04.29
increasing time
Voltage
P04.30 decreasing
time
Output
P04.31 maximum
voltage
Output
P04.32 minimum
voltage
P05.00
HDI input type
Detailed instruction of parameters
The function code is the voltage digital set value when the
voltage setting channel is selected as "keypad selection"
The setting range:0.0%~100.0%
Voltage increasing time is the time when the inverter
accelerates from the output minimum voltage to the output
maximum voltage.
Voltage decreasing time is the time when the inverter
decelerates from the output maximum voltage to the output
minimum voltage.
The setting range:0.0~3600.0s
Set the upper and low limit of the output voltage.
The setting range of P04.31:P04.32~100.0%(the rated
voltage of the motor)
The setting range of P04.32:0.0%~ P04.31(the rated voltage
of the motor)
P05 Group Input terminals
0: HDI is high pulse input. See P05.49~P05.54
IKR Aandrijven en Besturen
www.ikr-industries.nl
Keypad operation procedure
Default
Modify
value
○
100.0%
○
5.0s
○
5.0s
◎
100.0%
◎
0.0%
◎
0
