INVT Goodrive100 Series Instruction Manual page 133

Goodrive100 inverters
Function
Name
code
terminals state Range: 0000~000F
Digital
P17.14
adjustment
P17.15 Torque given
P17.16 Linear speed
P17.17 Reserved
P17.18 Counting value
AI1 input
P17.19
voltage
AI2 input
P17.20
voltage
Detailed instruction of parameters
Display the adjustment through the keypad of the inverter.
Range : 0.00Hz~P00.03
Display the torque given, the percentage to the current rated
torque of the motor.
Setting range: -300.0%~300.0%(the rated current of the
motor)
Display the current linear speed of the inverter.
Range: 0~65535
Display the current counting number of the inverter.
Range: 0~65535
Display analog AI1 input signal
Range: 0.00~10.00V
Display analog AI2 input signal
IKR Aandrijven en Besturen
www.ikr-industries.nl
Keypad operation procedure
Default
Modify
value
●
0.00V
●
0.0%
●
0
●
0
●
0
●
0.00V
●
0.00V
