INVT Goodrive100 Series Instruction Manual page 79

Goodrive100 inverters
Function
Name
code
Corresponding
setting of the
P05.43
lower limit of
AI3
middle value of
P05.44
AI3
Corresponding
P05.45 middle setting
of AI3
Upper limit of
P05.46
AI3
Corresponding
setting of
P05.47
the upper limit
of AI3
AI3 input filter
P05.48
time
HDI high-
P05.49 speed pulse
input function
Detailed instruction of parameters
The setting range of P05.46:P05.44~10.00V
The setting range of P05.47:-100.0%~100.0%
The setting range of P05.48:0.000s~10.000s
The function selection when HDI terminals is high-speed
pulse input
