INVT Goodrive100 Series Instruction Manual page 83

Goodrive100 inverters
Function
Name
code
on delay time the electrical level change during the programmable terminal
RO1 switching
P06.11
off delay time
RO2 switching
P06.12
on delay time
RO2 switching
P06.13
off delay time
AO1 output
P06.14
selection
AO2 output
P06.15
selection
HDO high-
speed pulse
P06.16
output
selection
Detailed instruction of parameters
switching on and off.
The setting range :0.000~50.000s
Note:P06.08 and P06.08 are valid only when P06.00=1.
0:Running frequency
1:Set frequency
2:Ramp reference frequency
3:Running rotation speed
4:Output current (relative to the rated current of the inverter)
5:Output current(relative to the rated current of the motor)
6:Output voltage
7:Output power
8:Set torque value
9:Output torque
IKR Aandrijven en Besturen
www.ikr-industries.nl
Keypad operation procedure
Default
Modify
value
○
0.000s
○
0.000s
○
0.000s
○
0
○
0
○
0
