INVT Goodrive100 Series Instruction Manual page 111

Goodrive100 inverters
Function
Name
code
Keypad PID
P09.01
preset
PID feedback
source
P09.02
Selection
PID output
P09.03 feature
selection
Detailed instruction of parameters
Note:
Multi-stage speed given, it is realized by
group parameters.
When P09.00=0, set the parameter whose basic value is the
feedback value of the system.
The setting range:-100.0%~100.0%
Select the PID channel by the parameter.
0:Analog channel AI1 feedback
1:Analog channel AI2 feedback
2:Analog channel AI3 feedback
3:High speed HDI feedback
4:MODBUS communication feedback
5~7:Reserved
Note: The given channel and the feedback channel can not
coincide, otherwise, PID can not control effectively.
0: PID output is positive: When the feedback signal exceeds
the PID given value, the output frequency of the inverter will
decrease to balance the PID. For example, the strain PID
control during wrapup
