INVT Goodrive100 Series Instruction Manual page 67

Goodrive100 inverters
Function
Name
code
Motor 1V/F
P04.03
Frequency
point 1
Motor 1V/F
Voltage
P04.04
point 1
Motor 1V/F
P04.05 Frequency
point 2
Motor 1V/F
P04.06
voltage point 2
Motor 1V/F
P04.07
Frequency
Detailed instruction of parameters
automatic torque boost.
Torque boost threshold: below this frequency point, the
torque boost is effective, but over this frequency point, the
torque boost is ineffective.
The setting range of P04.01:0.0%:(automatic)0.1%~10.0%
The setting range of P04.02:0.0%~50.0%
When P04.00 =1, the user can set V//F curve through
P04.03~P04.08.
V/F is generally set according to the load of the motor.
Note:V1＜V2＜V3,f1＜f2＜f3. Too high low frequency voltage
will heat the motor excessively or damage. The inverter may
occur the overcurrent speed or overcurrent protection.
The setting range of P04.03: 0.00Hz~P04.05
The setting range of P04.04, P04.06 and P04.08 :
0.0%~110.0%
The setting range of P04.05:P04.03~ P04.07
The setting range of P04.07:P04.05~P02.02(the rated
frequency of motor 1)
IKR Aandrijven en Besturen
www.ikr-industries.nl
Keypad operation procedure
Default
Modify
value
○
0.00Hz
○
00.0%
○
00.00Hz
○
00.0%
○
00.00Hz
