INVT Goodrive100 Series Instruction Manual page 188

Goodrive100 inverters
The inverter
GD100-0R7G-4
GD100-1R5G-4
GD100-2R2G-4
GD100-5R5G-4
GD100-7R5G-4
GD100-011G-4
GD100-004G-4
GD100-015G/-4
Note:
1. The input EMI meet the requirement of C2 after adding input filters.
2. Above options are external, the customer should indicate when purchasing.
C.7 Braking system
C.7.1 Select the braking components
It is appropriate to use braking resistor or braking unit when the motor brakes sharply or the motor is driven
by a high inertia load. The motor will become a generator if its actual rotating speed is higher than the
Input filter
FLT-P04006L-B
FLT-P04032L-B
FLT-P04016L-B
FLT-P04045L-B
IKR Aandrijven en Besturen
www.ikr-industries.nl
Appendix C
Output filter
FLT-L04006D
FLT- L04032D
FLT- L04014D
FLT- L04049D
