INVT Goodrive100 Series Instruction Manual page 101

Goodrive100 inverters
Function
Name
code
range 3
P08.15 Traverse range This function applies to the industries where traverse and
Sudden
jumping
P08.16
frequency
range
Traverse boost
P08.17
time
Traverse
P08.18
declining time
Detailed instruction of parameters
convolution function are required such as textile and
chemical fiber.
The traverse function means that the output frequency of the
inverter is fluctuated with the set frequency as its center. The
route of the running frequency is illustrated as below, of
which the traverse is set by P08.15 and when P08.15 is set
as 0, the traverse is 0 with no function.
Traverse range:The traverse running is limited by upper and
low frequency.
The traverse range relative to the center frequency: traverse
range AW＝center frequency×traverse range P08.15.
Sudden jumping frequency＝traverse range AW×sudden
jumping frequency range P08.16. When run at the traverse
frequency, the value which is relative to the sudden jumping
frequency.
The raising time of the traverse frequency: The time from the
lowest point to the highest one.
IKR Aandrijven en Besturen
www.ikr-industries.nl
Keypad operation procedure
Default
Modify
value
○
0.0%
○
0.0%
○
5.0s
○
5.0s
