Goodrive100 inverters

3.2.6 Input /Output signal connection figure

Please use U-shaped contact tag to set NPN mode or PNP mode and the internal or external power supply.
The default setting is NPN internal mode.
If the signal is from NPN transistor, please set the U-shaped contact tag between +24V and PW as below
according to the used power supply.
If the signal is from PNP transistor, please set the U-shaped contact tag as below according to the used
power supply.

3.3 Layout protection

3.3.1 Protecting the inverter and input power cable in short-circuit situations

Protect the inverter and input power cable in short circuit situations and against thermal overload.
Arrange the protection according to the following guidelines.
Note: Select the fuse as the manual indicated. The fuse will protect the input power cable from damage in
short-circuit situations. It will protect the surrounding devices when the internal of the inverter is short
circuited.
Fig 3-7 U-shaped contact tag
Diagram 3-8 NPN modes
Diagram 3-9 PNP modes
Fig 3-10 Fuse configuration
IKR Aandrijven en Besturen
www.ikr-industries.nl
Installation guidelines
