INVT Goodrive100 Series Instruction Manual page 44

Goodrive100 inverters Keypad operation procedure
Function Default
Name Detailed instruction of parameters Modify
code value
Note: when analog AI2 select 0~20mA input, the
corresponding voltage of 20mA is 10V.
100.0% of the analog input setting corresponds to the
maximum frequency (function code P00.03) in forward
direction and -100.0% corresponds to the maximum
frequency in reverse direction (function code P00.03)
4:High-speed pulse HDI setting
The frequency is set by high-speed pulse terminals.
Goodrive100 series inverters provide 1 channel high speed
pulse input as the standard configuration. The pulse
frequency range is 0.0~50.00kHz.
100.0% of the high speed pulse input setting corresponds to
the maximum frequency in forward direction (function code
P00.03) and -100.0% corresponds to the maximum
frequency in reverse direction (function code P00.03).
Note: The pulse setting can only be input by multi-function
terminals HDI. Set P05.00 (HDI input selection) to high speed
pulse input, and set P05.49 (HDI high speed pulse input
function selection) to frequency setting input.
5:Simple PLC program setting
The inverter runs at simple PLC program mode when
P00.06=5 or P00.07=5. Set P10 (simple PLC and multi-stage
speed control) to select the running frequency, running
direction, ACC/DEC time and the keeping time of
corresponding stage. See the function description of P10 for
detailed information.
