INVT Goodrive100 Series Instruction Manual page 29

Goodrive100 inverters
S2 Switch input 2
S3 Switch input 3
S4 Switch input 4
Except for S1~S4, this terminal can be used as high frequency input
channel.
HDI
Max. input frequency:50kHz
Terminal
name
+10V Local power supply +10V
1. Input range: AI2 voltage and current can be chose:
0~10V/0~20mA；AI2 can be shifted by J3
AI2
AI3:-10V~+10V
2. Input impedance:voltage input: 20kΩ; current input: 500Ω
3. Resolution: the minimum one is 5mV when 10V corresponds to 50Hz
AI3
IKR Aandrijven en Besturen
www.ikr-industries.nl
Installation guidelines
2. 12~30V voltage input is available
3. The terminal is the dual-direction input terminal
supporting both NPN and PNP
4. Max input frequency:1kHz
5. All are programmable digital input terminal. User
can set the terminal function through function
codes.
Description
