INVT Goodrive100 Series Instruction Manual page 64

Goodrive100 inverters
Function
Name
code
limit setting
source
selection
Braking torque
upper-limit
setting
P03.19
source
selection
Electromotion
torque upper-
P03.20
limit keypad
setting
Braking torque
P03.21 upper-limit
keypad setting
Weakening
P03.22
coefficient in
constant power
Detailed instruction of parameters
braking torque upper-limit setting source selection.
0:Keypad setting
P03.18,P03.21 sets P03.19)
1:Analog AI1 setting upper-limit torque
2:Analog AI2 setting upper-limit torque
3:Analog AI3 setting upper-limit torque
4:Pulse frequency HDI setting upper-limit torque
5:MODBUS communication setting upper-limit torque
6~8:Reserved
Note: setting method 1~9,100% corresponds to three times of
the motor current.
The function code is used to set the limit of the torque.
Setting range:0.0~300.0%(motor rated current)
The usage of motor in weakening control.
Function code P03.22 and P03.23 are effective at constant
IKR Aandrijven en Besturen
www.ikr-industries.nl
Keypad operation procedure
upper-limit frequency(P03.20
Default
Modify
value
sets
○
0
○
180.0%
○
180.0%
○
1.0
