Timer Counter-Reload Register - Crr; Timer Repetition Register - Repr - Holtek HT32F54231 User Manual

32-Bit Arm ® Cortex ® -M0+ MCU
HT32F54231/HT32F54241/HT32F54243/HT32F54253
Timer Counter-Reload Register – CRR
This register specifies the timer Counter-Reload value.
Offset: 0x088
Reset value: 0x0000_FFFF
31
Type/Reset
23
Type/Reset
15
Type/Reset RW 1 RW
7
Type/Reset RW 1 RW
Bits Field
[15:0] CRV
Timer Repetition Register – REPR
This register specifies the timer repetition counter value.
Offset: 0x08C
Reset value: 0x0000_0000
31
Type/Reset
23
Type/Reset
15
Type/Reset
7
Type/Reset RW 0 RW
Bits Field
[7:0] REPV
Rev. 1.00
30 29 28
22 21 20
14 13 12
1 RW 1 RW
6 5 4
1 RW 1 RW
Descriptions
Counter-Reload Value
The CRV is the reload value which is loaded into the actual counter register.
30 29 28
22 21 20
14 13 12
6 5 4
0 RW 0 RW
Descriptions
Repetition Counter Value
These bits allow the user to specify the update rate of the compare registers.
