Power Control Register - Pwrcr - Holtek HT32F54231 User Manual

32-Bit Arm ® Cortex ® -M0+ MCU
HT32F54231/HT32F54241/HT32F54243/HT32F54253
Power Control Register – PWRCR
This register provides power control bits for the different kinds of power saving modes.
Offset: 0x104
Reset value: 0x0000_0000
31
Type/Reset
23
Type/Reset
15
ULDOSTS
Type/Reset RO 0
7
ULDOON
Type/Reset RW 0
Bits Field
[19:18] WUP1TYPE WAKEUP1 Signal Trigger Type
[17:16] WUP0TYPE WAKEUP0 Signal Trigger Type
[15] ULDOSTS
[10] WUP1EN
Rev. 1.00
30 29 28
22 21 20
Reserved
14 13 12
Reserved
6 5 4
Reserved
Descriptions
WUP1TYPE WAKEUP1 Signal Trigger Type
[1:0]
0 0 Positive-edge Triggered
0
1 Negative-edge Triggered
1 0 High-level Sensitive
1 1 Low-level Sensitive
WUP0TYPE WAKEUP0 Signal Trigger Type
[1:0]
0 0 Positive-edge Triggered
0 1 Negative-edge Triggered
1
0 High-level Sensitive
1 1 Low-level Sensitive
Ultra-low Power Regulator Status
This bit is set to 1 if the ULDOON bit in this register has been cleared to 1 after MCU
is wakeup from the Deep-Sleep2 mode. This bit is cleared to 0 if the ULDOON bit
has been set to 0 or if a POR/PDR reset occurred.
External WAKEUP1 Pin Enable
0: Disable WAKEUP1 pin function
1: Enable WAKEUP1 pin function
The software can set the WUP1EN bit as 1 to enable the WAKEUP1 pin function
before entering the power saving mode. When WUP1EN = 1, a change on the
WAKEUP1 pin wakes up the system from the power saving mode. If the WAKEUP1
pin is active high, this bit will set an input pull down mode.
