32-Bit Arm ® Cortex ® -M0+ MCU
HT32F54231/HT32F54241/HT32F54243/HT32F54253
ADC Conversion List Register 0 – ADCLST0
This register specifies the conversion sequence order No.0 ~ No.3 of the ADC.
Offset: 0x004
Reset value: 0x0000_0000
31
Reserved
Type/Reset
23
Reserved
Type/Reset
15
Reserved
Type/Reset
7
Reserved
Type/Reset
Bits Field
[28:24] ADSEQ3
[20:16] ADSEQ2
[12:8] ADSEQ1
[4:0] ADSEQ0
Rev. 1.00
30 29 28
RW
22 21 20
RW
14 13 12
RW
6 5 4
RW
Descriptions
ADC Conversion Sequence Select 3
Select the ADC input channel for the 3
0x00: ADC_IN0
0x01: ADC_IN1
0x02: ADC_IN2
0x03: ADC_IN3
0x04: ADC_IN4
0x05: ADC_IN5
0x06: ADC_IN6
0x07: ADC_IN7
0x08: ADC_IN8
0x09: ADC_IN9
0x0A: Analog ground V
SSA
0x0B: V
DDA
0x0C: Internal Voltage Reference (V
0x0D: Analog power MV
DDA
0x0E ~ 0x1F: Invalid setting. These values must not be selected as it may cause
the ADC abnormal operations.
ADC Conversion Sequence Select 2
ADC Conversion Sequence Select 1
ADC Conversion Sequence Select 0
199 of 576
27 26
ADSEQ3
0 RW 0 RW 0 RW
19 18
ADSEQ2
0 RW 0 RW 0 RW
11 10
ADSEQ1
0 RW 0 RW 0 RW
3 2
ADSEQ0
0 RW 0 RW 0 RW
ADC conversion sequence.
rd
)
REF
(V /2)
DDA
25 24
0 RW 0
17 16
0 RW 0
9 8
0 RW 0
1 0
0 RW 0
January 28, 2022
