Bits Field
[4] CH0OCF
[3] CH3CCIF
[2] CH2CCIF
[1] CH1CCIF
Rev. 1.00
Descriptions
Channel 0 Over-Capture Flag
This flag is set by hardware and cleared by software.
0: No over-capture event is detected
1: Capture event occurs again when the CH0CCIF bit is already set and it is not
yet cleared by software.
Channel 3 Capture/Compare Interrupt Flag
- Channel 3 is configured as an output:
0: No match event occurs
1: The content of the counter CNTR has matched the content of the CH3CCR
register
This flag is set by hardware when the counter value matches the CH3CCR value
except in the center-aligned mode. It is cleared by software.
- Channel 3 is configured as an input:
0: No input capture occurs
1: Input capture occurs
This bit is set by hardware on a capture event. It is cleared by software or by
reading the CH3CCR register.
Channel 2 Capture/Compare Interrupt Flag
- Channel 2 is configured as an output:
0: No match event occurs
1: The content of the counter CNTR has matched the content of the CH2CCR
register
This flag is set by hardware when the counter value matches the CH2CCR value
except in the center-aligned mode. It is cleared by software.
- Channel 2 is configured as an input:
0: No input capture occurs
1: Input capture occurs.
This bit is set by hardware on a capture event. It is cleared by software or by
reading the CH2CCR register.
Channel 1 Capture/Compare Interrupt Flag
- Channel 1 is configured as an output:
0: No match event occurs
1: The content of the counter CNTR has matched the content of the CH1CCR
register
This flag is set by hardware when the counter value matches the CH1CCR value
except in the center-aligned mode. It is cleared by software.
- Channel 1 is configured as an input:
0: No input capture occurs
1: Input capture occurs
This bit is set by hardware on a capture event. It is cleared by software or by
reading the CH1CCR register.
