Power Connections

WARNING This instrument is electrically powered, and therefore all electrical connections must
be provided with good grounding.
Poor grounding can represent a danger to the operator and adversely affect the instrument
efficiency.

Performing Electrical Connections

 To connect autosampler cable
1. Connect the signal cable of the MAS Plus autosampler to the connector marked Autosampler, on
the back panel of the Elemental Analyzer.
 To connect RS232 cable
Perform this operation if the RS 232 serial line connection is required.
2. Connect the RS 232 cable supplied in the standard outfit between the COM1 or COM2 ports of
your computer and the 9-pin connector marked RS 232 on the instrument connection panel.
If your computer is equipped with USB ports, a Serial-to-USB adapter is required for properly
connecting the cable.
3. Plug in the instrument and computer power cables.
