Front Panel

The front panel of the Elemental Analyzer is shown in
Figure 7.
The front panel comprises:
• A furnaces compartment. Also see the section
• A LED status panel. Also see the section
• Oven compartment including the pressure regulators, pressure gauges, adsorption filters,
isothermal GC oven housing, the TCD detector, the gas chromatographic column, and the He
module. See the section
Note On the internal wall of the front door you will find holders designed for a paper copy of the
Consumables and Spare Parts Catalog, and tools for maintenance. See
Figure 8.
Thermo Scientific
Instrument Front Panel
"Oven Compartment"
Right Door Internal View
1
Getting Familiar with your EA IsoLink IRMS System for CNSOH
Figure 7.
LED Status Panel
Access to He
Absorption Filters, He and O
Access to Furnaces
"Furnaces Compartment"
"Status Panel" on page 25.
on page 16.
Consumable and Spare Parts Catalog
Tool Storage
EA IsoLink IRMS System for CNSOH Operating Manual
Front Panel
M
, Isothermal GC Oven and
pressure regulators
2
on page 13.
Figure 8.
Tools
M
