Installing MAS Plus Autosampler

This chapter provides the instruction for installing the MAS Plus autosampler on the Flash IRMS.
Contents
•

MAS Plus Autosampler Overview

• MAS Plus Autosampler Installation
MAS Plus Autosampler Overview
The MAS Plus autosampler for solid samples is provided with the Elemental Analyzer. See
Figure 64. MAS Plus Autosampler
It consists of:
• An anodized aluminum block (sampler body) provided on the left side with fittings for carrier gas
and reference gas lines connection.
• A 32-position sample-holding tray numbered 1 to 32. It is provided with a reference pin to be
introduced into the seat marked 1(one) which has a locating mark. See
Thermo Scientific
Figure
EA IsoLink IRMS System for CNSOH Operating Manual
4
Figure 64.
Sample Tray
Alignment Pin
Viewer
Sampler Body
Carrier Gas Inlet
Reference Gas Inlet
Autosampler Nut
Tray Motor Box
65.
