Table 8.
To convert
kPa
bar
psig

Transformers Compartment

Located in the right bottom part of the instrument, the compartment of the transformer is accessible
firstly by removing the back panel of the instrument, then by removing the relevant protection plate.
See Figure
Figure 23. Accessing the Transformer Compartment
Thermo Scientific
Pressure Units Conversion
Into Multiply By:
bar 0.01
psi 0.145
kPa 100
psi 14.51
kPa 6.89476
bar 0.0689476
23.
Back Panel
1
Getting Familiar with your EA IsoLink IRMS System for CNSOH
Transformer Compartment Protection Plate
EA IsoLink IRMS System for CNSOH Operating Manual
Transformers Compartment
23
