Getting Familiar with your EA IsoLink IRMS System for CNSOH
Transformers Compartment
The compartment contains the electrical devices for powering the furnaces and controlling their
temperature.
WARNING DO NOT OPEN the transformers compartment, there are no user serviceable parts
inside. Any operation inside the compartment must be carried out only by authorized and trained
Thermo Fisher Scientific personnel.
Figure 24
Figure 24. Transformer Compartment Internal View
LTA-2
24
EA IsoLink IRMS System for CNSOH Operating Manual
shows the devices contained in the compartment.
LTA-1 (HT)
PWR 1112 Board
Transformers
Thermo Scientific
