f.
g. In the field Elemental Analyzer Connection select the computer serial port (COM1, COM2,
h. In the field Instrument Settings choose the following settings:
i.
2. In Main Menu for IRMS click the icon
operating parameters are visualized. See
Thermo Scientific
Table 29. Main Menu for IRMS: Description of Icons (Graphic Buttons)
Icon
Function
Edit elemental analyzer
parameters
Elemental analyzer status
In Main Menu for IRMS select File | Instrument name and configuration and click
Elemental analyzer setup for visualizing the dialog window of
configuration parameters must be set.
Figure 152. Configuration Dialog Window
and so on), to which the instrument is connected.
• Line Frequency = 50 Hz
• TCD Settings Source = Internal
• TCD Settings Polarity = Positive
In the field Sampler Setting select the type of autosampler installed on the instrument.
• In the case of autosampler for liquid samples, also specify the serial port of the computer
to which the autosampler is connected, and the number of vials.
• Click Ok to go back to the window of
for IRMS.
9
Running the Flash IRMS as Stand-alone Instrument
Description
Gives the access to the three pages containing the commands
for setting temperatures, flows, times, detector, and the
analyzer control functions.
Comprises four pages displaying the analyzer conditions.
Figure
152, then click Ok to return to Main Menu
. The following window appears where the analyzer
Figure
153.
EA IsoLink IRMS System for CNSOH Operating Manual
Configuring the Analyzer
Figure
152, where the
145
