ATTENTION Do not dispose of the protection cap but keep it in your lab for future use.
The protection cap should be reinstalled on the coupling union in case the instrument is not used
for a long time. The washer and the conical O-ring removed are used for the installation of the
reactor.
4. Remove the MAS Plus autosampler, if installed, by manually undoing its fixing nut. See
Thermo Scientific
Figure 51. Protection Cap Removal
Left Channel - Pyrolysis
Right Channel - Combustion)
3
Installing Flash IRMS Elemental Analyzer
Installing the Reactors into the Furnaces
EA IsoLink IRMS System for CNSOH Operating Manual
Protection Cap
Reactor Retaining
Nut
Washer
Conical O-ring
Coupling Union
Bottom Feed
Connector
Protection Cap
Reactor Retaining
Nut
Washer
Conical O-ring
Coupling Union
Figure 52.
