Thermo Scientific EA IsoLink IRMS System Operating Manual page 94

4
Installing MAS Plus Autosampler
MAS Plus Autosampler Overview
Figure 65. Sample Tray
The modular design of the MAS Plus allows up to three additional 32-position sample trays can be
added to reach a capacity of 125 samples. Each sample tray is installed in a specific position
defined by the numbering, and therefore they are not interchangeable. See
Figure 66. Additional Sample Trays
The sample numbering is detailed in
Table 20. Sample Tray Numbering
Sample Tray
#1
#2
#3
#4
Any sample has to place in the locating mark position. The correct alignment of the locating
mark is important for the installation of the sample tray on the MAS Plus autosampler.
See
66 EA IsoLink IRMS System for CNSOH Operating Manual
Locating Mark
Seat marked 1 (one) from 1 to 32
Seat marked 0 (zero) from 33 to 63
Seat marked 0 (zero) from 64 to 94
Seat marked 0 (zero) from 95 to 125
Figure 67.
Locating Mark
Seat "one"
Additional
Sample Trays
(Drums)
Table 20.
Numbering
Purge/reference gas inlet
Figure 66
