The Grid Network ports listed in the port connectivity table are valid only for StorageGRID
version 11.6.0. To verify which ports are correct for each node type, you should always consult
the networking guidelines for your version of StorageGRID.
Steps
1. From the StorageGRID Appliance Installer, click Configure Networking > Port Connectivity Test
(nmap).
The Port Connectivity Test page appears.
The port connectivity table lists node types that require TCP connectivity on the Grid Network. For each
node type, the table lists the Grid Network ports that should be accessible to your appliance.
You can test the connectivity between the appliance ports listed in the table and the other nodes in your
Grid Network.
2. From the Network drop-down, select the network you want to test: Grid, Admin, or Client.
3. Specify a range of IPv4 addresses for the hosts on that network.
For example, you might want to probe the gateway on the network or the primary Admin Node.
Specify a range using a hyphen, as shown in the example.
4. Enter a TCP port number, a list of ports separated by commas, or a range of ports.
5. Click Test Connectivity.
◦ If the selected port-level network connections are valid, the "Port connectivity test passed" message
appears in a green banner. The nmap command output is listed below the banner.
