supplies.
Callout
1
2
3
4
5
This figure shows the back of the optional expansion shelf for the SG6060, including the input/output modules
(IOMs), fans, and power supplies. Each SG6060 can be installed with one or two expansion shelves, which
can be included in the initial installation or added later.
4
Description
Power supply (1 of 2) for SG6000-CN compute
controller
Connectors for SG6000-CN compute controller
Fan (1 of 2) for E2860 controller shelf
E-Series E2800 storage controller (1 of 2) and
connectors
Power supply (1 of 2) for E2860 controller shelf
