6. If you selected Static, follow these steps to configure the Admin Network:
a. Enter the static IPv4 address, using CIDR notation, for Management Port 1 on the appliance.
Management Port 1 is the left of the two 1-GbE RJ45 ports on the right end of the appliance.
b. Enter the gateway.
If your network does not have a gateway, re-enter the same static IPv4 address.
c. If you want to use jumbo frames, change the MTU field to a value suitable for jumbo frames, such as
9000. Otherwise, keep the default value of 1500.
The MTU value of the network must match the value configured on the switch port the
node is connected to. Otherwise, network performance issues or packet loss might
occur.
d. Click Save.
When you change the IP address, the gateway and list of subnets might also change.
If you lose your connection to the StorageGRID Appliance Installer, re-enter the URL using the new
static IP address you just assigned. For example,
https://services_appliance:8443
e. Confirm that the list of Admin Network subnets is correct.
You must verify that all subnets can be reached using the gateway you provided.
The default route cannot be made to use the Admin Network gateway.
▪ To add a subnet, click the insert icon
▪ To remove an unused subnet, click the delete icon
f. Click Save.
7. If you selected DHCP, follow these steps to configure the Admin Network:
a. After you select the DHCP radio button, click Save.
The IPv4 Address, Gateway, and Subnets fields are automatically populated. If the DHCP server is
set up to assign an MTU value, the MTU field is populated with that value, and the field becomes read-
only.
Your web browser is automatically redirected to the new IP address for the StorageGRID Appliance
Installer.
b. Confirm that the list of Admin Network subnets is correct.
You must verify that all subnets can be reached using the gateway you provided.
The default route cannot be made to use the Admin Network gateway.
▪ To add a subnet, click the insert icon
▪ To remove an unused subnet, click the delete icon
to the right of the last entry.
.
to the right of the last entry.
.
