NetApp StorageGRID SG6000 Manual page 12

1
2
3
10
Port
Interconnect ports 1 and 2 16-Gb/s FC optical SFPa
Management ports 1 and
2
Diagnostic and support
ports
Type
1-Gb (RJ-45) Ethernet
• RJ-45 serial port
• Micro USB serial port
• USB port
Use
Connect each of the
E2800 controllers to the
SG6000-CN controller.
There are four
connections to the
SG6000-CN controller
(two from each E2800).
• Port 1 Options:
◦ Connect to a
management
network to enable
direct TCP/IP
access to
SANtricity System
Manager
◦ Leave unwired to
save a switch port
and IP address.
Access SANtricity
System Manager
using the Grid
Manager or
Storage Grid
Appliance Installer
UIs.
Note: some optional
SANtricity functionality,
such as NTP sync for
accurate log timestamps,
is not available when you
choose to leave Port 1
unwired.
Note: StorageGRID 11.5
or greater, and SANtricity
11.70 or greater, are
required when you leave
Port 1 unwired.
• Port 2 is reserved for
technical support use.
Reserved for technical
support use.
