SG6060: E2800 storage controllers
• Two controllers for failover support.
• Manage the storage of data on the drives.
• Function as standard E-Series controllers in a duplex configuration.
• Include SANtricity OS Software (controller firmware).
• Include SANtricity System Manager for monitoring storage hardware and for managing alerts, the
AutoSupport feature, and the Drive Security feature.
• Connect to the SG6000-CN controller and provide access to the storage.
This figure shows the connectors on the back of each of the E2800 controllers.
Port
Admin Network port 2
Type
1-GbE (RJ-45)
Use
Options:
• Bond with
management port 1
for a redundant
connection to the
Admin Network for
StorageGRID.
• Leave unwired and
available for
temporary local
access (IP
169.254.0.1).
• During installation,
use port 2 for IP
configuration if DHCP-
assigned IP
addresses are not
available.
