6.5.4.1.5 Dimensions
All dimensions in mm.
15.5
19
15
6.5.4.1.6 Construction
Element
DVI
USB
Data
Control wires
Hot plug detection
Automation PC 3100 User's manual V 1.00 Translation of the original documentation
110 ± 10
54 34
Figure 83: 5CASDL.0xxx-03 ≥ Rev. E0 - Dimensions
36.5
55 110 ±10 37.5 ±2.5
Figure 84: 5CASDL.0xxx-03 ≤ Rev. D0 - Dimensions
Pinout Cross section
TMDS data 0 26 AWG
TMDS data 1 26 AWG
TMDS data 2 26 AWG
TMDS clock 26 AWG
XUSB0 26 AWG
XUSB1 26 AWG
SDL 26 AWG
DDC clock 24 AWG
DDC data 24 AWG
+5 V 24 AWG
Ground 24 AWG
24 AWG
Table 243: 5CASDL.0xxx-03 SDL flex cables - Construction
Length
Length
TMDS data 2
TMDS cycle
XUSB1
XUSB0
Accessories
TMDS data 1
TMDS data 0
Control wires
- DDC clock
- DDC data
- +5V
- Ground
- Hot plug detect
SDL
