2.3.1.1.3 Technical data
Information:
The following specified characteristic data, features and limit values are only valid for these individual
components and may differ from those of the complete system. The data specified for the complete
system applies to the complete system in which this individual component is used, for example.
Model number
General information
Cooling
LED status indicators
B&R ID code
Battery
Type
Service life
Removable
Design
Power button
Reset button
Buzzer
Certifications
CE
UL
HazLoc
DNV GL
Controller
Boot loader
Processor
Type
Clock frequency
Number of cores
Architecture
Thermal design power (TDP)
L2 cache
Intel 64 architecture
Intel Turbo Boost Technology
Intel Hyper-Threading Technology
Intel vPro Technology
Intel Virtualization Technology (VT-
x)
Intel Virtualization Technology for
Directed I/O (VT-d)
Enhanced Intel SpeedStep Tech-
nology
Chipset
Trusted Platform Module
Real-time clock
Precision
Battery-backed
Power failure logic
Controller
Buffer time
Memory
Removable
Memory slot
Number of memory channels
Type
Memory size
Max. memory bandwidth
Graphics
Controller
Color depth
DirectX support
OpenGL support
Power management
Table 42: 5APC3100.KBU0-000, 5APC3100.KBU1-000, 5APC3100.KBU2-000, 5APC3100.KBU3-000 - Technical data
Automation PC 3100 User's manual V 1.00 Translation of the original documentation
5APC3100.KBU0-000 5APC3100.KBU1-000
0xEF96
Temperature: B (0 - 55°C)
Humidity: B (up to 100%)
Vibration: A (0.7 g)
EMC: B (Bridge
and open deck)
3)
Intel C-3965U
2200 MHz
2 MB
No
No
No
Intel HD Graphics 610
5APC3100.KBU2-000
Passive via heat sink
Power, Disk, Link, Run
0xEF97 0xEF98
Renata 950 mAh
4 years
1)
Yes
Lithium ion
Yes
Yes
No
Yes
cULus E115267
Industrial control equipment
cULus HazLoc E180196
Industrial control equipment
for hazardous locations
Class I, Division 2, Groups ABCD, T4
-
UEFI BIOS
Intel i3-7100U Intel i5-7300U
2400 MHz 2600 MHz
2
14 nm
15 W
3 MB
Yes
Yes
Yes
Yes
Yes
Intel Kabylake-U
TPM 2.0
At 25°C: Typ. 12 ppm (1 second) per day
Yes
MTCX
5)
10 ms
Yes
2
DDR4 SDRAM
Max. 32 GB
34.1 GB/s
Intel HD Graphics 620
Max. 32-bit
12
4.4
ACPI 5.0
Technical data
5APC3100.KBU3-000
0xEF99
2)
Temperature: B (0 - 55°C)
Humidity: B (up to 100%)
Vibration: A (0.7 g)
EMC: B (Bridge
and open deck)
3)
Intel i7-7600U
2800 MHz
4 MB
Yes
Yes
4)
51
