B&R Automation PC 3100 User Manual page 138

Software
4.1.6.1.1 Create RAID volume
BIOS parameter
Name:
RAID level:
Select disks:
Disk n:
Stripe size:
Capacity:
Synchronization:
4.1.6.1.2 Disk n
BIOS parameter
Volume actions
1)
Reset to non-RAID
1)
Port:
Model number:
Serial number:
Size:
Status:
Controller type:
Controller interface:
1) Available only if the storage medium is part of a RAID volume.
4.1.6.1.3 RAID volume info
BIOS parameter
Volume actions
Delete
Enable master disk only
Enable recovery disk only
Name:
RAID level:
Strip size:
Size:
Status:
Bootable:
Disk n
1)
Table 153: Device manager - Intel® Rapid Storage Technology - RAID volume info
1) "Disk n" is a placeholder. This BIOS parameter displays a subset of the values that are listed in more detail in the corresponding submenu.
138
Setting options Description
String Name for the RAID volume
Default: Volume1 No special characters are permitted.
Range: Max. 16 characters
Selects the RAID level
RAID0 (stripe)
RAID1 (mirror)
Recovery
(Blank) Selects the storage medium for the RAID volume. Either X (RAID0 and RAID1) or M
(master) /R (recovery) can be defined (recovery mode).
X
M
R
4 KB Selects the data block size [kB]
8 KB
16 KB
32 kB
64 KB
128 KB
INT Defines the RAID memory size [MB]
Range: Hardware-dependent
If storage media of different sizes are used, this is limited to the smaller medium.
Continuous Selects the synchronization mode
On request
Table 151: Device manager - Create RAID volume
Setting options Description
Enter Resets the disk to non-RAID
- Displays the port number of device n
- Displays the product ID of device n
- Displays the serial number of device n
- Displays the memory size of device n
- Displays the RAID status of device n
- Displays the controller of device n
- Displays the controller interface of device n
Table 152: Device manager - Intel® Rapid Storage Technology
Setting options Description
Enter Deletes the RAID volume
Enter Enables only the master disk
Enter Enables only the recovery disk
- Displays the name of the RAID volume
- Displays the RAID level of the volume
- Displays the data block size [kB] of the volume
- Displays the memory size [GB or TB] of the volume
- Displays the status of the volume
- Displays the bootability of the volume
Enter Opens submenu
Automation PC 3100 User's manual V 1.00 Translation of the original documentation
"Disk n" on page 138
