BIOS parameter
Interrupt
MTCX interrupt
Note:
COM B to COM E are only displayed if they are allocated.
BIOS parameter
COM B
Base I/O address
Interrupt
COM C
Base I/O address
Interrupt
COM D
Base I/O address
Interrupt
COM E
Base I/O address
Interrupt
Automation PC 3100 User's manual V 1.00 Translation of the original documentation
Setting options Description
0x3F8
IRQ 3 Selects the interrupt for COM A
IRQ 4
IRQ 5
IRQ 7
IRQ 11
Disables the MTCX interrupt or assigns it automatically if permitted by the system con-
Automatic
figuration (at least 1 IRQ free).
Disable
Table 158: Advanced - OEM features - Super IO
Setting options Description
Disable Disables/Enables COM B (LFP touch screen)
Enable
0x2E8 Selects the I/O address of port COM B
0x2F8
0x338
0x378
0x3E8
0x3F8
IRQ 3 Selects the interrupt for COM B
IRQ 4
IRQ 5
IRQ 7
IRQ 11
Disable Disables/Enables COM C (IF option 1)
Enable
0x2E8 Selects the I/O address of port COM C
0x2F8
0x338
0x378
0x3E8
0x3F8
IRQ 3 Selects the interrupt for COM C
IRQ 4
IRQ 5
IRQ 7
IRQ 11
Disable Disables/Enables COM D (IF option 2)
Enable
0x2E8 Disables/Enables the I/O address of port COM D
0x2F8
0x338
0x378
0x3E8
0x3F8
IRQ 3 Selects the interrupt for COM D
IRQ 4
IRQ 5
IRQ 7
IRQ 11
Disable Disables/Enables COM E (graphics option IF3)
Enable
0x2E8 Selects the I/O address of port COM E
0x2F8
0x338
0x378
0x3E8
0x3F8
IRQ 3 Selects the interrupt for COM E
IRQ 4
IRQ 5
IRQ 7
IRQ 11
Table 159: Advanced - OEM features - Super IO (supplement)
