MicroWash+ Microplate Washer User Guide

Select the Format of the Microplate Type

You can select the 8-strip, 12-strip, or 16-strip format for the microplate type. The strip
formats correspond to the number of channels in the manifold.
The standard 8-channel manifold works with 96-well plates in portrait orientation.
The optional 12-channel manifold works with 96-well plates in landscape orientation.
The optional 16-channel manifold works with 384-well plates in portrait orientation.
Figure 7-25: The Plate Format prompt
Table 7-20: Actions of Control Panel Buttons
Button
On the left
On the right
98
Action
Press this button to return to the previous step. See
the Microplate Type on page
Press this button to end the process and return to Define Plate without saving any
changes. See Defining a Microplate Type on page
Press this button to scroll forward through the microplate formats: 8-strip, 12-strip,
or 16-strip
Press this button to scroll backward through the microplate formats: 16-strip, 12-
strip, or 8-strip
Press this button to confirm the format and then define the well shape for the
microplate type. See Select the Well Shape of the Microplate Type on page
Confirm or Change the Name of
96.
77.
99.
5032022 C
