Define the Second Side for Crosswise Aspiration

This option is available only for flat-bottom microplates with crosswise aspiration enabled.
This option defines the position of the microplate for the second step of a crosswise
aspiration. Molecular Devices recommends that you place the aspiration needle close to the
edge that is opposite from the first aspiration position.
Figure 7-32: The second side for crosswise aspiration
You can define the second side for crosswise aspiration by editing the offset value, or by
using the "teach-in" method.
Figure 7-33: The Side Position Rear prompt
Table 7-25: Actions of Control Panel Buttons
Button
On the left
On the right
5032022 C
Action
Press this button to end the process and return to Define Plate without saving any
changes. See Defining a Microplate Type on page
Press this button to move the microplate to the currently saved second side position
and switch to "teach-in" mode. See
Aspiration on page 104.
Press this button to increase the offset value by 0.1 mm to a maximum of 5.0 mm.
Press this button to decrease the offset value by 0.1 mm to a minimum of –5.0 mm.
Press this button to accept the displayed offset value and then define the aspiration
height. See Define the Height for Aspiration on page
Chapter 7: Defining a Microplate Type
77.
Teach-In the Second Side for Crosswise
105.
