Define the Height for Aspiration

Define the height of the manifold during aspiration for the microplate type.
Figure 7-10: Aspiration height
You can define the aspiration height by editing the offset value, or by using the "teach-in"
method.
Figure 7-11: The Aspiration Height prompt
Table 7-10: Actions of Control Panel Buttons
Button
On the left
On the right
5032022 C
Action
Press this button to end the process and return to Define Plate without saving any
changes. See Defining a Microplate Type on page
Press this button to move the microplate to the currently saved aspiration position
and switch to "teach-in" mode. See
Press this button to increase the offset value by 0.1 mm to a maximum of 18.8 mm.
Press this button to decrease the offset value by 0.1 mm to a minimum of 0.0 mm.
Press this button to accept the displayed offset value and then define the dispense
position. See Define the Dispense Position on page
Chapter 7: Defining a Microplate Type
77.
Teach-In the Height for Aspiration on page
89.
88.
87
