MicroWash+ Microplate Washer User Guide
Teach-In the Overflow Dispense Height
Use the "teach-in" method to define the dispense height for an Overflow wash.
Figure 7-21: The Overflow Dispense Height "teach-in" prompt
Table 7-17: Actions of Control Panel Buttons
Button
On the left
On the right
94
Action
With displayed on the left, press this button to detect and move the aspiration
needle to the bottom of the well.
With displayed on the left, press this button to move the manifold up.
Press this button to move the microplate to the currently saved overflow dispense
position.
Press this button to increase the offset value by 0.1 mm to a maximum of 18.8 mm.
Press this button to decrease the offset value by 0.1 mm to a minimum of 0.0 mm.
Press this button to accept the displayed offset value and then save the parameters
for the microplate type definition.
5032022 C
