Chapter 5: Defining a Procedure

Before running procedures with the MultiWash+ Microplate Washer, select the instrument
set up options, define the microplate types, define the wash or rinse cycles, and then define
the procedures.
To select the instrument set up options, see
page
To define the microplate types, see
To define the wash or rinse cycles, see
To edit or define a procedure, scroll the LCD display to Define Procedure. From Define
Procedure, define and save procedures using defined cycles and defined microplate types.
Tip: If you have a previously defined procedure, you can create a similar new
procedure by editing an existing procedure and giving it a new name.
Figure 5-1: The Define Procedure menu option
Table 5-1: Actions of Control Panel Buttons
Button
On the left
On the right
5032022 C
113.
Action
Press this button to scroll to Prime/Rinse. See
on page 31.
Press this button to scroll to Define Cycle. See
65.
Press this button to scroll forward through the list of previously defined procedures.
If you want to edit a previously defined procedure, scroll until the name is displayed.
If you want to define a new procedure, scroll until <new> is displayed.
Press this button to scroll backward through the list of previously defined procedures.
If you want to edit a previously defined procedure, scroll until the name is displayed.
If you want to define a new procedure, scroll until <new> is displayed.
Press this button to start defining the procedure. See
52.
Selecting Instrument Set Up Options on
Defining a Microplate Type on page
Defining a Wash or Rinse Cycle on page
Priming or Rinsing the Fluidics System
Defining a Wash or Rinse Cycle on page
Defining the Procedure on page
5
77.
65.
51
