MicroWash+ Microplate Washer User Guide
Teach-In the Dispense Position
Use the "teach-in" method to define the dispense position.
Figure 7-40: The Dispense Position "teach-in" prompt
Table 7-30: Actions of Control Panel Buttons
Button
On the left
On the right
108
Action
With displayed on the left, press this button to detect and move the aspiration
needle to the bottom of the well.
With displayed on the left, press this button to move the manifold up.
Press this button to move the microplate to the currently saved dispense position.
Press this button to increase the offset value by 0.1 mm to a maximum of 5.0 mm.
Press this button to decrease the offset value by 0.1 mm to a minimum of –5.0 mm.
Press this button to accept the displayed offset value and then define the dispense
height for a Bottom wash. See Define the Bottom Dispense Height on page 109.
