MicroWash+ Microplate Washer User Guide
Teach-In the Side for Aspiration
Use the "teach-in" method to define the side of the well for aspiration, or the first side of the
well for crosswise aspiration.
Figure 7-31: The Side Position Front "teach-in" prompt
Table 7-24: Actions of Control Panel Buttons
Button
On the left
On the right
102
Action
With displayed on the left, press this button to detect and move the aspiration
needle to the bottom of the well.
With displayed on the left, press this button to move the manifold up.
Press this button to move the microplate to the currently saved aspiration position.
Press this button to increase the offset value by 0.1 mm to a maximum of 5.0 mm.
Press this button to decrease the offset value by 0.1 mm to a minimum of –5.0 mm.
Press this button to accept the displayed offset value.
If crosswise aspiration is enabled, then you can define the second side for aspiration.
See Define the Second Side for Crosswise Aspiration on page
If crosswise aspiration is disabled, then you can define the aspiration height. See
Define the Height for Aspiration on page
103.
105.
