Define the Side for Aspiration

This option defines the position of a flat-bottom microplate for aspiration. If crosswise
aspiration is enabled, then this option defines the position for the first step of a crosswise
aspiration. Molecular Devices recommends that you place the aspiration needle close to the
edge the well in a flat-bottom microplate.
Figure 7-29: Aspiration position
You can define the side for aspiration by editing the offset value, or by using the "teach-in"
method.
Figure 7-30: The Side Position Front prompt
Table 7-23: Actions of Control Panel Buttons
Button
On the left
On the right
5032022 C
Action
Press this button to end the process and return to Define Plate without saving any
changes. See Defining a Microplate Type on page
Press this button to move the microplate to the currently saved aspiration position
and switch to "teach-in" mode. See
Press this button to increase the offset value by 0.1 mm to a maximum of 5.0 mm.
Press this button to decrease the offset value by 0.1 mm to a minimum of –5.0 mm.
Press this button to accept the displayed offset value.
If crosswise aspiration is enabled, then you can define the second side for aspiration.
See Define the Second Side for Crosswise Aspiration on page
If crosswise aspiration is disabled, then you can define the aspiration height. See
Define the Height for Aspiration on page
Chapter 7: Defining a Microplate Type
77.
Teach-In the Side for Aspiration on page
105.
102.
103.
101
