MicroWash+ Microplate Washer User Guide
Teach-In the Center of the Well for Aspiration
Use the "teach-in" method to define the center of the well for aspiration.
Figure 7-9: The Center Position "teach-in" prompt
Table 7-9: Actions of Control Panel Buttons
Button
On the left
On the right
86
Action
With displayed on the left, press this button to detect and move the aspiration
needle to the bottom of the well.
With displayed on the left, press this button to move the manifold up.
Press this button to move the microplate to the currently saved center position.
Press this button to increase the offset value by 0.1 mm to a maximum of 5.0 mm.
Press this button to decrease the offset value by 0.1 mm to a minimum of –5.0 mm.
Press this button to accept the displayed offset value and then define the aspiration
height. See Define the Height for Aspiration on page 87.
5032022 C
