Hardware
Item
Name
8
Serial ports
Back panel and LEDs
Item
Name
1
Power and fan item
2
WWAN2
3
CORE module
4
WWAN1
5
Reset
Digi Connect IT® 16/48 User Guide
Description
Connect equipment to a serial port to provide console access to
the equipment through the cellular network. See
equipment to the Connect IT serial
Connect IT 16: serial ports 1-16.
n
Connect IT 48: serial ports 1-48.
n
The LED on the left lights:
Yellow: There is activity on the port.
n
Green: The port is in use.
n
The LED on the right for ACT lights yellow.
Description
Connect the power supply and fan unit to the device.
For installation information, see
supplies and
Antennas can be attached if the module is used to
complete a cellular connection. See
hardware and connect to a cellular
The CORE module is used to complete a cellular
connection. See
cellular
network.
Antennas can be attached if the module is used to
complete a cellular connection. See
hardware and connect to a cellular
Press this switch to reset the device.
See
Use the RESET button to reset your device to the
factory
defaults.
Back panel and LEDs
Connect
ports.
Connect the power
fans.
Connect
network.
Connect hardware and connect to a
Connect
network.
